F type
CERAM-F3

Split stone design gives eaves a sharp, modern look on any shape of roof.
  • Natural stone design (Schiefer) on surface
  • Supports system construction
  • Flat roofing tiles with excellent waterproof and construction performance

Color Variation

  • STRAIGHT BLACK
    32
  • MATTE SILVER BLACK
    23
  • MATTE BROWN
    33
  • RUSTY GREEN
    27

Specification * Standard measurements

Actual Length 355mm
Actual Width 338mm
Exposed Length 280mm
Exposed Width 303mm
Weight 3.7kg
Tiles per ㎡ 12
Tiles weight per ㎡ 44kg
Water Absorption 6%

Disaster-resistant Tiles/S-PRO

Provide enhanced resistance against natural disasters and wind. The bottom tile’s lock arm joins firmly with the upper tile’s overlap lock during installation. This interlocking structure withstands wind.
Patent number 3502309

Disaster-resistant Tile/S-PRO

Disaster-resistant Clip Style

Thorough and reliable disaster-resistant construction method that secures tiles using binding metal brackets based on construction guidelines.
This construction makes on-site adjustment during roofing work easier.

Supported from 2.5 sun (14 degree pitch)

We conducted a 2.5 sun (14 degree) pitch waterproof test using the disaster-resistant clip tiles.
They demonstrated superior waterproof performance through greater 15 mm overlap.
* Be sure to inquire with our sales staff when placing your order.

Waterproof Shape

Through rain resistance through rainwater diffusion. Patented flashing offers excellent waterproof performance.
Appealing design accented with horizontal lines. Produces a delicate texture
Patent no. 2829281

System Tiles

These tiles offer both beautiful finish and simplified construction. They are also eco-friendly, with waste reduced to about 20%.
  • CERAM-F3: Disaster-resistant clip style, 5 sun (26.5 degree)/4.5 sun (24.2 degree)/4 sun (21.8 degree) pitch standard production
  • CERAM-FF: Disaster-resistant tile style, 5 sun (26.5 degree)/4.5 sun (24.2 degree)/4 sun (21.8 degree) pitch standard production
  • Please specify System Tiles when ordering.

System Tiles

Integrated Verge Tiles

Keep your roof looking simple. Left and right verge tiles integrate for a beautiful finish.
Please specify Integrated Verge Tiles when ordering.

Solar Power/Roof Mount Type

Install as-is on your current roof. Wide variety lets you to select the most efficient type.

Universal Support Tiles

Install solar panels on your roof safely!

Snow Guard Tiles

Mitigates snow falling from roof. Also adds accent to roof design.
Corresponds to all CERAM-F series colors.
Please specify Snow Guard when ordering.

* Note: May not stop all snowfall depending on weather conditions.
* For installation details, consult with a construction professional.
